The NTG3 is a broadcast-grade shotgun microphone designed for the most demanding shoots that require high-resolution broadcast audio. It features RF-bias technology that yields superior resistance to moisture and condensation, making it suitable for outdoor shoots in adverse conditions. The NTG3 has a rich, warm sound and a tightly controlled polar pattern with exceptional off-axis performance with no coloration. It is also highly regarded for voice-over work, where its natural tone and punch deliver exceptional performance for a wide range of voice types.
Key Features
- Broadcast-grade RF-bias shotgun microphone
- Highly resistant to moisture and condensation
- Tightly controlled directional pick-up without off-axis coloration
- Available in satin-nickel or matte black finish
Specifications
Acoustic & Electrical
| Acoustic Principle |
Line Gradient |
| Active Electronics |
RF Bias |
| Capsule |
0.50" |
| Polar Pattern |
Supercardioid |
| Address Type |
End |
| Frequency Range |
40Hz - 20kHz |
| Output Impedance |
25Ω |
| Maximum SPL |
130dB SPL |
| Maximum Output Level |
8.2mV (@ 1kHz, 1% THD into 1KΩ load) |
| Sensitivity |
-30.0dB re 1 Volt/Pascal (31.60mV @ 94 dB SPL) +/- 2 dB @ 1kHz |
| Equivalent Noise Level (A-Weighted) |
13dBA |
| Power Requirements |
P48 |
Mechanical
| Weight (g) |
163 |
| Dimensions (mm) |
255 (H) x 19 (W) x 19 (D) |
| 255 (H) x 19 (W) x 19 (D) |
Satin-Nickel |
