RCF NX 15-SMA Active Coaxial Stage Monitor

RCF NX 15-SMA Active Coaxial Stage Monitor Features

• 1400 Watt Peak, 700 Watt RMS digital bi-amplification
• 130 dB max spl
• 60° x 60° constant directivity horn
• 15" High power neodymium woofer, 2.5" voice coil
• 1.7" kapton dome, 1" exit, neodymium high frequency driver
• DSP processing, floor - fre field equalization, soft limiter and protection
• Combo xlr/jack input, xlr signal output

RCF NX 15-SMA Active Coaxial Stage Monitor Specifications

Specification	Details
Frequency Response	50 Hz – 20,000 Hz
Max SPL @ 1m	130 dB
Horizontal Coverage Angle	60°
Vertical Coverage Angle	60°
Compression Driver	Coaxial 1.0" neo, 1.75" voice coil
Woofer	Coaxial 15" neo, 2.5" voice coil
Input Signal	Balanced / unbalanced
Input Connectors	XLR, jack
Output Connectors	XLR
Input Sensitivity	+4 dBu
Crossover Frequencies	1700 Hz
Protections	RMS, HF
Limiter	Soft limiter
Controls	Freefield, floor
Total Power	1400 W peak, 700 W RMS
High Frequencies	400 W peak, 200 W RMS
Low Frequencies	1000 W peak, 500 W RMS
Cooling	Convection
Connections	Powercon IN/OUT
Safety Agency	CE compliant
Cabinet / Case Material	Baltic birch plywood
Handles	1 on side
Pole Mount / Cap	35 mm insert
Grille	Steel
Color	Black
Dimensions (H x W x D)	362 x 650 x 468 mm (14.25 x 25.59 x 18.43 in)
Weight	20.2 kg (44.53 lb)
Package Dimensions (H x W x D)	714 x 464 x 569 mm (28.11 x 18.27 x 22.4 in)
Package Weight	24.5 kg (54.01 lb)
