The RCF DMA 162P is a powerful two-channel Class-D power amplifier delivering 320 W total output with advanced DSP, RCF speaker presets, FIR filters, and scalable multi-room architecture. Designed for both desktop and rack installations in commercial and
Description for RCF DMA 162P 320W Two-Channel Power Amplifier EU – Black
DMA 162P is a two channels Class-D power amplifier, equipped with a powerful DSP platform. Its natural use is in combination with a DMA unit, in order to increase installed power and implement multi-room architectures for Commercial Audio systems. However, its adaptability, control tools, and available inputs allow using it as a stand-alone amplifier: in fact, adding the optional RDNet board the user can manage all DSP functions and choose the specific RCF speakers preset. Thanks to the extremely compact size, accurate design, and robustness, it is ideal for a wide range of business music applications.
-
Features
- 2 x 160 W Class-D power amplifier
- 20 ÷ 20000 Hz frequency range
- Full on-board processing
- RCF speakers’ presets
- Proprietary bass enhancer algorithm
- FiRPHASE linear phase filters
- Flexible and scalable multi-room architecture
- Suitable for desktop or rack installation
- RDNet ready for networked management
| Specification |
Details |
| Product Type |
Two-Channel Power Amplifier |
| Part Number |
12100028 (EU) |
| Amplifier Class |
Class-D |
| Output Power (RMS all channels driven) |
2 x 160 W @ 4 Ω, 2 x 160 W @ 8 Ω |
| Bridged Output Power |
1 x 320 W @ 4 Ω, 1 x 320 W @ 8 Ω |
| Output Power @ 70 V |
1 x 320 W @ 70 V |
| Frequency Response (-3 dB) |
20 Hz – 20 000 Hz |
| SNR (Analog inputs) |
>93 dB |
| Distortion (THD+N) @ 1 kHz |
<0.01% |
| Total Number of Inputs |
6 |
| Balanced Inputs |
4 |
| Unbalanced Inputs |
2 |
| Mono Inputs |
4 |
| Stereo Inputs |
2 |
| Line Inputs |
6 |
| General Purpose Inputs (GPI) |
2 |
| Signal Output Number |
1 |
| DSP |
Yes |
| EQ Filters |
Yes |
| FIR Filters |
Yes |
| Compressors |
Yes |
| Tone Controls |
Yes |
| High-Pass Filter |
80 Hz – 200 Hz |
| RCF Speaker Presets |
Yes |
| Protections |
Forced cooling, short circuit, thermal, DC, fuses, VHF |
| Operating Voltage |
90-240 V~ 50/60 Hz |
| Max Power Consumption |
400 W |
| Safety Agency |
CE compliant, UL 62368-1 |
| Cabinet Material |
Metal |
| Color |
Black |
| Rack Mounting |
1/2 19″, 1U (optional rack accessory required) |
| Height |
44 mm / 1.73 inches |
| Width |
213 mm / 8.39 inches |
| Depth |
304 mm / 11.97 inches |
| Weight |
1.65 kg / 3.64 lbs |
| Package Height |
106 mm / 4.17 inches |
| Package Width |
360 mm / 14.17 inches |
| Package Depth |
381 mm / 15 inches |
| Package Weight |
2.65 kg / 5.84 lbs |
|
