| Frequency Range (-10dB) |
30 Hz – 120 Hz |
| Frequency Response (±3dB) |
39 Hz – 107 Hz |
| Power Rating |
900 W continuous program (2 hrs)
450 W (1800 W peak) continuous pink noise (2 hrs)
300 W (1200 W peak) continuous pink noise (100 hrs) |
| Sensitivity |
85.5 dB (avg 40 Hz – 105 Hz) |
| Maximum SPL |
118 dB peak (111 dB continuous, 2 hr) @ 1m |
| Coverage Pattern |
Omnidirectional |
| Nominal Impedance |
6Ω (at 6Ω tap) |
| Transformer Taps |
70V: 200 W, 100 W, 50 W
100V: 200 W, 100 W |
| Driver |
305 mm (12 in) driver, polypropylene injection cone, thermoplastic vulcanizate surround, 50 mm (2 in) voice coil on glass fiber former |
| Terminals |
Bare wire with dielectric-gel-filled wire nuts (1 meter single jacketed cable, 7 wires with 14 AWG) |
| Enclosure Material |
LDPE polyethylene plastic, 6 mm minimum wall thickness, color throughout |
| Color |
Pine Green RAL 6028, or Beige Grey RAL 7006 |
| Dimensions |
842 mm height x 400 mm diameter (34.2 x 15.8 in) |
| Net Weight |
16.2 kg (35.7 lb) |
| Included Accessories |
(7) wire nuts |
