| Frequency Response (±3dB) |
75 Hz – 20 kHz |
| Power Capacity |
175 W |
| Amplifier Power Rating |
175 W |
| Sensitivity |
89 dB SPL, 1W, 1m (3.3 ft) |
| Maximum SPL (1m) |
111 dB continuous, 117 dB peak |
| Directivity Factor (Q) |
2.8 |
| Directivity Index (DI) |
4.5 |
| Impedance |
4 ohms |
| Crossover Frequency |
3 kHz |
| Polarity |
Positive voltage to + terminal causes outward low-frequency cone motion |
| Drivers |
LF Driver: 165 mm (6.5 in)
HF Driver: 25 mm (1 in) |
| Input Connectors |
Spring-loaded terminals |
| Enclosure |
Polypropylene structural foam |
| Grille |
Zinc-plated steel |
| Mounting Hardware |
Mounting points — no bracket included |
| Colors |
Black or white |
| Dimensions (H x W x D) |
387 x 251 x 229 mm (15.25 x 9.875 x 9 in) |
| Net Weight (each) |
4.5 kg (10 lb) |
| Shipping Weight (pair) |
11 kg (24 lb) |
| Note |
Molded of dense polypropylene. Accessory attachment points on rear of the enclosure are 1/4 x 20 threaded brass bushings. |
