| Frequency Range |
32 Hz – 300 Hz |
| Power Rating |
IEC system long-term ratings (low-Z direct):
200 W continuous program power
100 W continuous pink noise (400 W peak), 100 hrs |
| Sensitivity |
95 dB (near corner), 89 dB (center of ceiling) |
| Coverage Angle |
Omnidirectional |
| Transformer Taps |
80 W, 40 W, 20 W (& 10 W @ 70V), plus transformer bypass |
| Impedance |
8 ohms (in bypass mode) |
| Drivers |
200 mm (8 in) subwoofer |
| Termination |
Screw-down removable locking clip-in connector |
| Satellite Outputs |
Connectors for 2 or 4 Control 42C satellite speakers |
| Input Connectors |
6 removable locking 2-pin connectors with screw-down terminals |
| Dimensions (Diameter x Depth) |
332 mm diameter x 338 mm depth (13.1 in x 13.3 in) |
| Maximum SPL (1m) |
109 dB (low-impedance, 115 dB peak, center of ceiling)
115 dB (low-impedance, 121 dB peak, near corner)
108 dB (70V/100V, center of ceiling)
114 dB (70V/100V, near corner) |
| Color |
White |
| Safety Agency |
Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849. |
| Backcan |
Formed steel (included, "blind-mount") |
| Baffle/Rim |
ABS baffle with UL94-V0 and UL94-5VB flame class fire rating |
| Ceiling Cutout Size |
307 mm diameter (12.1 in) (cardboard cutout template included) |
| Included Accessories |
C-rings, tile rails, paint shield, cutout template, grille |
| Optional Accessories |
MTC-19NC new construction bracket
MTC-19MR mud ring construction bracket |
| Plenum Usage |
Yes, backcan included |
