| Frequency Range (-10dB) |
30 Hz – 20 kHz |
| Power Rating |
200 W peak
100 W continuous program power
50 W continuous pink noise |
| Sensitivity |
90 dB SPL |
| Coverage Angle |
180° H x 160° V |
| Impedance |
8 ohms |
| Drivers |
LF: 200 mm (8 in) polymer-coated aluminum cone, pure butyl rubber surround
HF: 25 mm (1 in) pure-titanium dome with cloth suspension on low-diffraction swivel-mount with -10° aimability |
| Input Connectors |
Screw-down Euroblock-type connector. Max wire size 14 AWG (1.5 mm²). |
| Crossover Network |
2nd order low-pass to the woofer and 2nd order high-pass to the tweeter |
| Optimum Air Cavity Behind Speaker |
40 to 80 liters (1.4 to 2.8 cu ft) |
| Outside Dimensions (H x W x D) |
334 x 257 x 110 mm (13.1 x 10.1 x 4.3 in), 102 mm (4.0 in) front of wall to back of speaker |
| Maximum Wall Thickness |
32 mm (1.25 in) |
| Cutout Size (H x W) |
300 x 225 mm (11.9 x 8.9 in). Cutout template included. |
| Net Weight (each) |
2.6 kg (5.5 lb) |
| Shipping Weight (each) |
5.9 kg (13.0 lb) |
| Included Accessories |
Cutout template & paint shield |
| Optional Accessories |
WB8 rough-in frame for new construction installation to wall studs |
