- Transducers:
- 916G 15” ferrite magnet woofer
- 196H 6” ferrite magnet transducer
- JBL 2408H-2 1.5” poly-annular diaphragm compression driver
- Updated JBL image control waveguides improve dispersion
- FEA flared port design reduces air noise and distortion
- Low-noise, low-distortion gain staging design
- Lightweight, efficient Class D amplification
- Power: 2,000 watts peak/1,000 watts RMS
- Frequency response: 40 Hz - 20 kHz @4pi (-10 dB); 46 Hz - 18 kHz @4pi (-3 dB)
- Dispersion: 90° x 50°
- Max SPL: 136.1 dB
- Crossover frequency: 542Hz; 2100Hz
- Color LCD screen provides access to comprehensive DSP suite
- DriveRack Technology includes Automatic Feedback Suppression, system limiter and 180 ms of speaker delay in 100-microsecond intervals for precise time-aligned systems
- Optimized presets for pairing full-range speakers with subwoofers
- JBL Pro Connect app allows full system control of up to 10 JBL Pro Connect app-enabled speakers and systems
- 18 mm birch cabinet with optimized bracing delivers smooth, accurate low-frequency response
- I/Os:
- 2 XLR balanced Combo jacks
- 1 3.5mm aux
- 2 XLR-M loop-through
- 1 XLR-M mix out
- Two integrated side handles
- Suspension/mounting: single 36mm pole socket, eight M10 suspension points
- Quiet fanless operation
- Ultra-low system latency: <1ms
- Net weight: 36.6 kg (80.6 lbs); gross weight: 42 kg (92.5 lbs)
- Dimensions: 938.5 mm x 446 mm x 434 mm (36.9 in x 17.5 in x 17.1 in) (H x W x D)
- Shipping dimensions: 990 mm x 535 mm x 535 mm (38.9 in x 21 in x 21 in) (H x W x D)
