| Drivers |
Sixteen 50 mm (2 in) full-range |
| Frequency Range (-10dB) |
80 Hz – 20 kHz |
| Coverage Angle |
Vertical: Switchable — Narrow Mode: 15° (±10°), Broad Mode: 40° (±10°)
Horizontal: 150° (±20°) |
| Sensitivity |
Narrow: (speech mode) 96 dB (2 kHz – 14 kHz) / (music mode) 93 dB (300 Hz – 18 kHz)
Broad: (speech mode) 93 dB (2 kHz – 14 kHz) / (music mode) 90 dB (300 Hz – 18 kHz) |
| Impedance |
5 ohms (in thru mode) |
| Power Capacity |
325 W (1300 W peak), 2 hrs
200 W (800 W peak), 100 hrs |
| Maximum SPL (1m) |
Narrow: (speech mode) 121 dB cont avg (127 dB peak) / (music mode) 118 dB cont avg (124 dB peak)
Broad: (speech mode) 118 dB cont avg (124 dB peak) / (music mode) 115 dB cont avg (121 dB peak) |
| Transformer Taps |
120 W, 60 W, 30 W (15 W at 70V only), and 8Ω thru, via switch |
| Enclosure |
Fiberglass reinforced ABS cabinet, painted aluminum grille |
| Outdoor Capability |
IP-55 rated, per IEC529, when installed with optional MTC-PC2 panel cover. UV, moisture, and 200-hr ASTM G85 acid-air/salt-spray resistant. |
| Color |
Black or white (-WH) |
| Insert Points |
18 M6 insert points on back panel |
| Mounting |
Included swivel (pan)/tilt wall bracket provides continuously variable ±80° left-right swivel aiming (at no up/down tilt), continuously adjustable ±15° tilt, plus 5° fixed increment points. Eighteen threaded mounting points on back panel conform to industry-standard rectangular 108 x 51 mm (4.25 x 2.0 in) pattern for OmniMount® 30.0 and other compatible third-party brackets. Threaded mounting points can also be used for suspension. |
| Dimensions (H x W x D) |
1000 x 98.5 x 153 mm (39.4 x 3.8 x 6.0 in) |
| Net Weight |
7.2 kg (15.8 lb) |
| Included Accessories |
Swivel (pan)/tilt wall bracket |
| Optional Accessories |
MTC-PC2 terminal panel cover
MTC-CBT-FM1 flush-mount low-profile wall-mount bracket
MTC-CBT-SMB1 stand-mount bracket for use with 35 mm speaker stand |
